Open up your vehicle to fresh air and light! This upgraded version of the Dometic Midi Heki Style roof light has improved safety features, aerodynamics, appearance and maintenance.
This Dometic Midi Heki Style is an advanced version of Dometic's mid-sized roof windows. It features a newly designed dome with double acrylic glazing for enhanced insulation and better visual integration. With its improved design, the Midi Heki Style is both easier to clean and generates up to 20 % (3 dB) less noise thanks to improved aerodynamics. An inner frame with separately adjustable darkening blind and fly screen conveniently keep sunlight and insects out of the vehicle. This advanced Midi Heki Style is available with crank or lever operation, with or without forced ventilation.
Open up your vehicle to fresh air and light! This upgraded version of the Midi Heki Style roof light has improved safety features, aerodynamics, appearance and maintenance. With well-proven benefits such as the darkening blind and fly screen, as well as hassle-free cleaning, it ensures comfort and convenience while you're on the road.
This tilting roof window freshens any motorhome or caravan with fresh air and light. This model combines top quality, durable materials and ease of operation with a full set of features.
DESIGNED IN DETAILThe Midi Heki Style is a real highlight even just to look at from the outside: The elegant roof dome with its hidden outer frame looks good on the roof of every vehicle. Midi Heki Style proves itself a "problem solver" for longitudinal installation situations, bringing light and air into the space below. Of course, it also boasts all the convenience features from the Dometic Midi Heki series: designer inner frame with variably adjustable darkening and fly screen, simple operation by crank, double acrylic glass glazing.
SIMPLE CRANK OR LEVER OPERATIONThe dome can be opened or closed by crank with a very smooth and quality action. The more popular is the simple lever version to open and close dome.
What's the difference between with or without fixed ventilation?Without Fixed VentilationThis means when the Dometic Mini Heki Style is closed it is completely sealed. There is no ventilation. This is the best option for a motorhome. If a motorhome owner decided to fit a "with fixed ventilation" rooflight, the air would flow through the ventilation gap whilst driving and likely cause a wind noise or whistling. This obviously doesn't matter in a caravan!
With Fixed VentilationWhen the rooflight is completely closed there is still a small amount of ventilation. This helps prevent damp and is the option that should be used in caravans.
Features
- Separately adjustable darkening and fly screens
- Well insulated dome with double acrylic glazing
- Improved aerodynamics reduce by 20 %
- Hinge and lock integrated into frame for improved safety and mechanical reliability
- Opens to three positions: fully open, half-open and bad-weather position
- With or without forced ventilation
- Modern design for stylish interior and exterior appearance
RE-DESIGNED FRAMEHinge and lock integrated into frame for improved safety and mechanical reliability
KEEP IT CLEANNew shape means less dirt between roof and dome
IMPROVED AERODYNAMICSNoise level is reduced by up to 20 % (3 dB)
The Dometic Midi Heki comes with an installation kit for a roof thickness of 30mm - 34mm. If your roof thickness is more or less than this size you will require an extra kit. Please see below:
Quick View Dometic Midi Heki additional installation kits for roof thickness 25 - 29mm
Quick View Dometic Midi Heki additional installation kits for roof thickness 30 - 34mm
Quick View Dometic Midi Heki additional installation kits for roof thickness 35 - 42 mm
Quick View Dometic Midi Heki additional installation kits for roof thickness 43 - 52mm
Quick View Dometic Midi Heki additional installation kit for roof thickness 53 - 60mm
Specifications
- Dimensions product depth : 617 mm
- Dimensions product width : 846 mm
- Dimensions ordered width : 700 mm
- Dimensions ordered height : 500 mm
- Dimensions opening width : 585 mm
- Dimensions opening height : 404 mm
- Net weight : 8,2 kg
- Standard mount. material thickness 1 min : 30 mm
- Standard mount. material thickness 1 max : 34 mm
- Possible material thickness 1 min : 25 mm
- Possible material thickness 1 max : 29 mm
- Cut out : 700 x 500mm
- Opening angle max : 45.00 ° (Lever Version) / 60.00 ° (Crank Version)
- Positions fixed : 3 (Lever Model)
- Certificates eMark
